Material :
Acetal (POM)Flow :
1/8 '' SizeSealing Ring :
Buna-N (Nitrile rubber)Color :
White / BeigeValve Option :
No ValveClassification:
Color and Material | Product Name | Operation temperature | O-ring |
![]() |
PACR1002B02 | - 40 ° F to 180° F | Buna-N (Nitrile rubber) |
![]() |
/ | - 32 ° F to 160° F | Peroxide Cured EPDM |
Panel Mount Dimensions:
Panel Opening | Max Panel Thickness | Min Panel Thickness | |
Sockets | .438" | .21" | 0.03" |
Plugs | .438" | .21" | 0.03" |
Product Number Guide Example:
P | AC | R | 100 | 2 | B | 02 |
Socket / Plug |
Material |
No Valve |
Flow size |
Body shape |
O-ring |
Connection size |
